Product picture	Product number	Description	Location
	Flanges - TC - Outlet - Adaptor
	1014MTP00010	Flange 1½" BSP Inner thread PCD125 open slot M16	G-14
	1014MTP00020	Flange 2" BSP Inner thread PCD125 open slot M16	DD-42
	1014MTP00030	Flange 1½" BSP Outer thread PCD125 4-hole Ø18mm	AA-35
	1014MTP00040	Flange 2" BSP Outer thread PCD125 4-hole Ø18mm	G-14
	1014MTP00045	Flange 2" BSP PCD125, ID50, 4-hole Ø18mm, T10mm	F-10
	1014MTP00050	Flange 1½" BSP Inner thread PCD168 6-hole Ø14mm	F2
	1014MTP00060	PV Valve Burst Adaptor 2½" [Top part] BSP Inner thread	DD-01
	1014MTP00070	PV Valve Burst Adaptor 2½" [Bottom part] BSP Outer thread 6xM10
	1014MTP00080	Dip tube adaptor PCD160 4xM16 - 4x pothole Ø18mm	G26
	1014MTP00090	3" Stub pipe adaptor flange PCD168 6xØ14mm - PCD160 4xØ18mm	G-15
	1014MTP00092	3" Stub Pipe adaptor flange PCD168 6x14mm PCD160, 4xØ18mm WITHOUT PIPE	F22
	1014MTP00095	Ring for stub pipe adaptor	DD-42
	Flanges - TC - Outlet - Adaptor
	1014MTP00100	Reducing Flange 3" > 2" OD Ø200mm ID Ø50mm 4xslotted hole - 4xM16
	1014MTP00101	Reducing Flange 3" > 2" OD Ø200mm ID Ø50mm 4xslotted hole - 4xM16	F11-B
	1014MTP00110	Flange Outlet 3" BSP round holes Ø18mm
	1014MTP00120	Flange Outlet 3" BSP slotted holes	F-4
	1014MTP00121	3” Breathing Socks – BLACK	H-13 / F12
	1014MTP00122	3” Breathing Socks – WHITE
	1014MTP00150	Reducer Flange 2”- 1½”, 4x M10 PCD103,5mm, 4x Ø18mm PCD125mm, T20mm	F11-B
	1014MTP00155		F-23
	TYPE 10	TYPE 10 DEN HARTOGH	F11-B
	Flanges TC Weld-in
	1014MTP04010	Weld-in DN50 4xM16 PCD125 ODØ165mm IDØ50mm	F1
	1014MTP04020	Weld-in 4xM10 [ Ball Valve 1½" BSP and Flanged ]	G16
	1014MTP04030	Weld-in 4xM16 [PV Valve 3" Flanged ]
	1014MTP04040	Weld-in 6xM8 [ PV Valve 2½ " BSP ]
	1014MTP04050	Weld-in 8xM12 [Bottom discharge 3" 45° ODØ200mm]
	1014MTP04060	Weld-in 8xM12 [Bottom discharge 3" 45° ODØ200mm, steamheatable ]
	1014MTP04070	Weld-in 6xM12 Low profile [ Top discharge ]
	1014MTP04080	Weld-in closure plate ODØ127mm, T 6mm [ Bottom discharge ]	CC13
	1014MTP04090	Weld-in closure plate ODØ127mm, T 8mm [ Bottom discharge ]
	1014MTP04100	Weld-in 6xM12 PCD168 - 4xM16 PCD160 [ Butterfly Valve 3" Flanged ]
	1014MTP04110	Weld-in Low profile 6xM12 PCD168 - 4xM16 PCD160 [ Butterfly Valve 3" Flanged ]
	1014MTP04120	Weld-in 4xM16 PCD125 Low profile [ Butterfly Valve/Ball Valve 2" BSP and Flanged ]
	Flanges TC Blind
	1014MTP01010	Blind Flange 2" PCD125 mm, T 10mm, 4-hole Ø18mm	F22
	1014MTP01012	Blind Flange 2" PCD125 mm, T 6mm, 4-hole Ø18mm
	1014MTP01020	Blind Flange 3" PCD160mm/PCD145mm 4-slotted holes 18mm, T 10mm [ Top discharge ] Ansi & Din
	1014MTP01030	Blind Flange 3" PCD160 mm, T 10 mm, OD Ø200mm 4-hole Ø18mm,
	1014MTP01040	Blind Flange PCD168 mm, 6-hole Ø14mm [ Top discharge ]	AA-37
	1014MTP01050	Blind Flange 6-hole Ø14mm [ PV Valve 2½" BSP ]	F-10
	1014MTP01060	Blind Flange 1½" PCD103 mm, 4-hole Ø12mm [ Airline ]	G17
	1014MTP01070	Blind Flange 8-hole Ø14mm PCD 178 mm [ for closing bottom discharge ]
	1014MTP01080	Blind Flange DN80 Dished end, 178mm
	Flanges DIN
	1015MTP00005	Slip-on Flange DN25 , PN10
	1015MTP00010	Slip-on Flange DN32 , PN10
	1015MTP00020	Slip-on Flange DN40, PN10	DD-01
	1015MTP00030	Slip-on Flange DN50, PN10	F1
	1015MTP00040	Slip-on Flange DN80, PN10	F4
	1015MTP00050	Slip-on Flange DN100, PN10
	1015MTP00060	Slip-on Flange DN125, PN10
	1015MTP00190	Blind Flange DN25, PN10
	1015MTP00200	Blind Flange DN32, PN10	DD-02
	1015MTP00210	Blind Flange DN40, PN10	DD-01
	1015MTP00220	Blind Flange DN50, PN10	F3 / F11 / I4 / AA-43
	1015MTP00230	Blind Flange DN80, PN10	D-32
	1015MTP00240	Blind Flange DN100, PN10
	1015MTP00250	Blind Flange DN125, PN10
